Designation
|
Order No.
|
|
Manufacturer options
|
|
|
Axis/spindle, each additional
|
6FC5800?0AC20?0YB0
|
|
Positioning axis/auxiliary spindle, each additional
|
6FC5800?0AC30?0YB0
|
|
TRANSMIT/Peripheral surface transformation
|
6FC5800?0AM27?0YB0
|
|
Pair of synchronized axes (gantry axes), basic
|
6FC5800?0AS51?0YB0
|
|
Travel to fixed stop with Force Control
|
6FC5800?0AM01?0YB0
|
|
Generic coupling basic CP basic1)
|
6FC5800?0AM72?0YB0
|
|
Sag compensation, multi-dimensional (bidirectional compensation)
|
6FC5800?0AM55?0YB0
|
|
Master/slave for drives, basic
|
6FC5800?0AS52?0YB0
|
|
Evaluation of internal drive variables
|
6FC5800?0AS53?0YB0
|
|
SINUMERIK Operate runtime license OA Easy Screen
|
6FC5800?0AP64?0YB0
|
|
Drive Based Safety Integrated Extended Functions
|
6SL5800?0AC50?0AA0
|
|
User options
|
|
|
Advanced Technology
(expansion of the technology cycles for turning and milling)2)
|
6FC5800-0AP58-0YB0
|
|
Extended operator functions3)
|
6FC5800?0AP16?0YB0
|
|
ShopTurn/ShopMill sequence programming
|
6FC5800?0AP17?0YB0
|
|
Residual material detection and machining for contour pockets and cutting
|
6FC5800?0AP13?0YB0
|
|
3D simulation of the finished part
|
6FC5800?0AP25?0YB0
|
|
Simultaneous recording (real-time simulation of current machining)
|
6FC5800?0AP22?0YB0
|
|
Measuring cycles for drilling/milling and turning
|
6FC5800?0AP28?0YB0
|
|
Network drive management
|
6FC5800?0AP01?0YB0
|
|
Replacement tools for tool management
|
6FC5800?0AM78?0YB0
|
|
RCS Host remote diagnostics function
|
6FC5800-0AP30-0YB0
|
|
Contour handwheel
|
6FC5800?0AM08?0YB0
|
|
Spline interpolation (A, B and C splines)
|
6FC5800?0AS16?0YB0
|
