Cooling
|
Forced ventilation
|
Water cooling
|
|
Rated power Prated (S1)
|
3.7 ... 100 kW (5 … 134 HP)
|
Up to 10000 rpm
|
|
Maximum speed
|
12000 rpm
|
7.5 ... 30.9 kW (10.1 … 41.4 HP)
|
|
Rated torque Mrated
|
23.6 ... 750 Nm (17.4 ... 553 lbf-ft)
|
48 ... 197 Nm
(64.4 ... 264 lbf-ft)
|
|
Type of construction in accordance with EN 60034-7 (IEC 60034-7)
|
- IM B3 (IM V5, IM V6)
- IM B5 (IM V1, IM V3, only possible with 1PH710/1PH713)
- IM B35 (IM V15, IM V35)
|
Supplied in component form, assembled on user's premises
|
|
Encoder systems, built-in
|
Incremental encoder
|
Hollow-shaft measuring system
|
|
Sound pressure level LpA (1 m) in accordance with EN ISO 1680
|
70 ... 76 dB
if the external fan unit is operated on a 50 Hz supply system
Tolerance +3 dB
|
Depending on spindle design
|
|
Degree of protection in accordance with EN 60034-5 (IEC 60034-5)
|
IP55
Fan IP54
|
IP00
or as specified by spindle manufacturer
|
|
Insulation of the stator winding in accordance with EN 60034-1 (IEC 60034-1)
|
Temperature class 155 (F) for a coolant temperature (air)
of up to 40 °C (104 °F)
|
Temperature class 155 (F) for a coolant inlet temperature
of up to 25 °C (77 °F)
|
|
Type of motor
|
Squirrel-cage induction motor
|
Squirrel-cage induction motor
|
|
Type of connection
|
Star connection
|
Selectable star/delta connection1)
|
|
Paint finish
|
No paint finish/primed
Anthracite (option)
|
Unpainted
|
|
Holding brake
|
–
|
Using spindle design
|
|
Mounted gearing
|
Prepared (option)
|
–
|
